Overview
The GCEM40E hot extractive multi-channel gas analyser is CODEL’s industry-proven continuous emissions monitor for difficult applications. Designed exclusively for use on a wide range of applications where the flue gas temperature is abnormally high, low or saturated.
Three decades of development, knowledge and practical experience have been utilised to produce this advanced technology gas analyser which gives complete flexibility of use on process or emissions applications whilst delivering superb accuracy and repeatability at a competitive price.
Features & Benefits
- Single or Multi-species infrared absorption analyser.
- Hot Extractive System.
- CO, NO, NO2, NOx, SO2, CH4, HCI, CO2 & H2O.
- Gas temperature and pressure sensors.
- Analogue & serial digital output.
GCEM40E Case Study
Read our GCEM40E case study from Eagle Valley Clean Energy, LLC owns and operates a 12MW biomass power plant, generating electricity from combustion of waste wood.
Product Specification
| Gas Species Options | CO2 & H2O as standard plus up to maximum 4 gases from: CO, NO, NO2, NOx, SO2, HCl, CH4 with optional O2. |
| Measuring units | ppm | mg/Nm³ | mg/m³ | % |
| Response Time | Less than 200 Seconds (T90)- MCERTS Specification |
| Ambient Temperature | -20°C to +50°C |
| Power supply (Cabinet) | 220 - 240VAC @ Min 2500W |
| Construction | Corrosion resistant epoxy coated aluminium housing sealed to IP66 |
| Analogue outputs | 4-20mA current outputs for each gas channel supplied isolated. 500O load max fully configurable from software |
| Logic Outputs | up to 8 x volt-free SPCO contacts 50V 1A max. Configurable as alarm contacts | 1 x volt-free SPCO contact 50V 1A max for data valid signal |
| Serial Data | RS485 |
You can find the full specification in the product data sheet / brochure.
